SAGLIN-GST-1060 + SAGLIN-GUVY-1060CS
Screen Cold Foil
Stamping Line
A stop-cylinder screen press feeding an inline cold foil & spot UV unit — the volume route to metallic decoration on premium packaging, with no engraved dies and no heat management.
One screen press.
One cold foil & spot UV unit. One line.
The SAGLIN Screen Cold Foil Stamping Line pairs the SAGLIN-GST-1060 full-automatic stop-cylinder screen press with the SAGLIN-GUVY-1060CS inline cold foil and spot UV unit. The screen press lays down the UV-curable adhesive pattern with ≤0.1 mm registration; the cold foil unit transfers metallic foil through that adhesive at room temperature, then applies spot UV varnish — all in one continuous B1 pass.
“Cold foil at room temperature, spot UV without an extra pass, and metallic decoration with no engraved dies — on a single screen-press line.”
Because cold foil bonds through UV adhesive rather than a heated die, artwork changes use screens and printing plates only — there is no die-making lead time and no heat-management overhead. The result is a flexible, fast-changeover finishing line for short and medium premium runs.
The line is the entry point into the SAGLIN finishing platform. Its modular splicing design means a hologram cast & cure module can be added later to upgrade to the full three-process line — without replacing the screen-press base.
Every line ships with electrical and pneumatic specifications adapted for the Russian and CIS markets (380V / 50Hz, EAC support). Installation, commissioning, and operator training are handled by our partner HD RUS LLC in the Moscow region.
Why converters choose this line
- Stop-cylinder screen press — ≤0.1 mm registration, up to 4,000 sheets/h
- Cold foil stamping at room temperature — no engraved dies
- Inline spot UV varnishing in the same pass
- Foil return & step function — saves foil, narrow-foil multi-up stamping
- Cold-air paper receiving prevents post-cure deformation
- Upgradeable to hologram cast & cure (ACS line) later
Two units, one continuous pass.
The line is built from two spliced units. Sheets feed from the screen press straight into the cold foil & spot UV unit — no manual transfer between processes.
Stop-Cylinder Screen Press
Classical stop-cylinder technology for high reliability, high precision, and low maintenance cost. Lays down the UV adhesive pattern and spot UV coating that the cold foil transfer relies on.
- Registration accuracy ≤0.1 mm
- Printing speed 500–4,000 sheets/h
- Max paper size 1060 × 900 mm
- Low noise, low maintenance, high automation
Cold Foil & Spot UV Unit
Inline cold foil stamping plus spot UV varnishing, with cold-air paper receiving and an IR drying array. Modular splicing design — compact structure, strong compatibility, easy maintenance on demand.
- Cold foil stamping + spot UV in one pass
- Foil return & step function (min gap 2–3 cm)
- Multiple narrow foils for different-effect stamping
- Cold-air paper receiving prevents deformation
Verified line specifications.
Specifications for both units in the line. Power supply is AC 380V / 50Hz / 3-phase, adaptable to the local grid on request.
Screen Press Unit
SAGLIN-GST-1060| Max paper size | 1060 × 900 mm |
| Min paper size | 560 × 350 mm |
| Max printing size | 1050 × 740 mm |
| Paper thickness | 90–420 g/m² |
| Registration accuracy | ≤0.1 mm |
| Screen frame size | 1300 × 1170 mm |
| Margin | ≤12 mm |
| Printing speed | 500–4,000 sheets/h |
| Power | 3-phase 380V / 50Hz / 11.0 kW |
| Weight | 5,500 kg |
| Overall dimensions | 3,800 × 3,100 × 1,750 mm |
Cold Foil & Spot UV Unit
SAGLIN-GUVY-1060CS| Process | Cold foil stamping + spot UV varnishing |
| Max working size | 1060 × 740 mm |
| Min working size | 546 × 393 mm |
| Max stamping size | 1030 × 730 mm |
| Paper weight | 128–450 g/m² |
| Max film roll diameter | Φ400 mm |
| Max film width | 1060 mm |
| UV lamp | 8 kW × 3 |
| IR lamp (UV / IR unit) | 1.2 kW × 3 |
| IR lamp (cold foil unit) | 3 kW × 4 |
| Max speed — spot UV | 4,000 sheets/h |
| Max speed — cold foil | 2,500 sheets/h |
| Total power | ≈ 75 kW |
| Overall dimensions | 7.5 × 3.0 × 3.8 m |
| Total weight | ≈ 6 T |
Maximum speed depends on paper specification, UV varnish viscosity, cold foil adhesive, and transfer film. Cold foil requires paper of 128 g/m² or above. Under test conditions (128–150 g/m², working format ≤ 600 × 500 mm) sustained cold foil speed is around 1,000 sheets/h; spot UV and hologram processes reach higher rates. Specifications subject to continuous improvement.
What sets the line apart.
Engineered for high-volume premium packaging. Here is what differentiates it from generic cold foil machines in the same class.
Modular Splicing Design
Single machine or multi-module combination. Compact structure, strong compatibility. Add a hologram module later to upgrade to the three-process line.
Cold Foil at Press Speed
Foil transfer through UV-curable adhesive at room temperature. No engraved dies, no heat management — artwork changes use screens and plates only.
Foil Return & Step Function
Foil return and step movement achieve a minimum gap of 2–3 cm between stampings, and multiple narrow foils can run together — substantial foil savings on every job.
Cold-Air Paper Receiving
Cold air system prevents post-cure deformation of UV-varnished sheets at high stacking heights — clean, flat stacks straight off the line.
Mitsubishi PLC Control
Centralised PLC controller with color touchscreen HMI. Job memory for recurring artwork, one-key test run, all functional data displayed in real time.
Keyence Optical Detection
Front and pull-side gauges use Keyence (Japan) fiber optic detection. Photoelectric paper-presence detection — auto-deceleration on miss-feed.
Material Saving & Recyclable
Cold foil protects the print and can replace a separate gloss pass; the laser film is recyclable without treatment. More economical than composite lamination.
Schneider & Yaskawa Electrics
Schneider main electrical control gear, Yaskawa frequency converters. Stable system reliability with reduced maintenance over multi-shift production.
Where the line performs.
Designed for premium packaging segments where metallic decoration and high-gloss finishes drive shelf appeal. The line is widely used on paper and board, and on plastic sheet packaging.
Perfume & Skincare Boxes
Cold-foil metallic effects with spot UV gloss on luxury cosmetics packaging — the workhorse application for premium beauty converters, combining decoration with a protective UV layer in one pass.
Wine & Liquor Cartons
Metallic cold-foil decoration and spot gloss on wine and spirits cartons and labels. Fast changeover suits the short, frequent runs typical of premium beverage brands.
Luxury Cartons & Covers
Gift boxes, high-end retail cartons, food and confectionery decorative packaging, and premium publication covers. Also used on digital-product and toy packaging.
Need hologram security too? Upgrade the line.
Add a hologram cast & cure module to run cold foil, hologram, and spot UV on a single pass — the SAGLIN-GUVY-1060ACS line. Thanks to the modular splicing design, the screen-press base stays the same.
See the Hologram Line →
Built with global-brand components.
The line ships with a global-brand component baseline — no compromise to lower the price point.
Questions buyers ask before signing.
What is the realistic production speed for cold foil?
Can I add hologram transfer later?
How does the foil saving function work?
What is the lead time and payment structure?
Is the line EAC certified for the Russian market?
Can the line connect to my existing offset press?
What installation and training is included?
Request a quote for your cold foil line.
Tell us your sheet size, target speed, and packaging segment. We respond within 24 hours with a detailed quotation, line layout proposal, and EAC documentation plan.
SAGLIN Machinery
Product Solution Manager, Packaging & Post-Press: Michelle Zhang
Email: michellezhang@sanlinmach.com
WhatsApp / WeChat: +86 153-5621-5089
Response time: within 24 hours
HD RUS LLC — Strategic Partner
Panfilova str. 19, bld. 1
Khimki, 141407 Moscow region
Product Manager, Packaging Print Postpress
Roman Frolov · +7 916 805 6265
· Detailed price quotation with payment terms
· Floor layout drawing for your factory
· ROI estimate based on your packaging mix
· Hologram upgrade path, if relevant
· EAC documentation plan and lead time
Explore the other finishing lines.
Cold Foil & Hologram Transfer Line
Adds hologram cast & cure to the cold foil platform — three premium decorations on one inline pass for anti-counterfeit packaging.
View specifications →
Screen Spot UV Coating Line
