SAGLIN-DX-1450
High-Speed
Flute Laminator
Servo-driven precision for corrugated and cardboard lamination — engineered for premium box converters and high-volume packaging factories.
Built for premium box production lines.
The SAGLIN-DX-1450 is a fully automatic high-speed flute laminator designed for converting printed top sheets onto single-flute (A–N) and multi-ply (3–7) corrugated boards or grey paperboard above 300 gsm. It operates as a stand-alone unit or as the core station of a complete corrugated box production line, paired with our SAGLIN-DX-FZ1450 automatic flip-flop stacker.
“From servo-controlled offset feeding to ±1 mm registration accuracy at 12,000 sheets per hour — the SAGLIN-DX-1450 is engineered to eliminate operator-dependent variation.”
What sets the SAGLIN-DX-1450 apart is the combination of dual-servo bottom-sheet feeding with multi-sensor registration control. This means a single operator can run the line all day without touching the alignment — a critical advantage for factories scaling beyond two shifts.
The machine ships with all electrical and pneumatic specifications adapted for the Russian and CIS markets (380V / 50Hz, EAC certification support), and can be installed and commissioned by our partner HD RUS LLC in Moscow within 14 days of arrival on site.
Why operators choose SAGLIN-DX-1450
- Servo-controlled offset feeder — no setup change between sheet sizes
- Dual-servo bottom feeder for stable 2–7 ply running
- Knurled stainless gluing roller — 25–30 gsm glue consumption
- PLC touch-screen with job memory & one-key test run
- Auto grease lubrication system (DALOMA) — minimal downtime
- Designed for two-shift operation by a single operator
Complete data sheet.
Verified specifications for the SAGLIN-DX-1450 main unit. The full production line includes the SAGLIN-DX-FZ1450 automatic flip-flop stacker (specifications available on request).
Lamination tolerance and effective speed depend on board quality, pre-cut precision, and operator experience. At a stable feed of 12,000 sheets/h with calibrated paper, accuracy below 1.0 mm is repeatedly achievable. Specifications subject to change without notice as part of continuous improvement.
SAGLIN-DX-1450 with full safety enclosure — line view
Full-Body Safety EnclosureOptional
For factories operating under strict workplace safety regulations or seeking a cleaner, more professional shop-floor appearance, the SAGLIN-DX-1450 can be supplied with a full-body white safety enclosure covering the feeder, gluing section, and registration unit.
- Operator Safety Compliance Fully encloses moving parts of the feeder and gluing section — meets stricter EU/EAC machinery directive expectations for two-shift operations.
- Reduced Noise & Dust Emission Acoustic damping panels lower in-cabin noise by an estimated 4–6 dB at peak production speed; paper dust is contained within the enclosure.
- Premium Factory Image Clean white industrial styling — well suited to factories receiving regular customer or brand-owner audits, especially in premium packaging and FMCG segments.
- Service Access Preserved Hinged inspection doors with safety interlocks retain full access to the feeder, gluing unit, and bridge for setup, cleaning, and maintenance.
Enclosure dimensions and exact configuration are quoted per project — additional lead time approximately 7–10 working days, EAC documentation included. Ask Michelle for pricing.
Eight structural advantages.
Every section of the machine is engineered for stability at maximum speed. Here is what differentiates the SAGLIN-DX-1450 from generic flute laminators in the same price range.
Servo-Controlled Offset Feeder
Shaftless servo drive handles 120–600 gsm without setup change. Pre-loading device standard. Over-lapping feed ensures smooth running of low-gsm stocks.
Dual-Servo Bottom Feeder
Two servo motors — one for accurate feeding timing, one for intermittent suction control. Big air blower with separate belt holders runs 2–5 ply and cardboard without belt vibration.
Precision Gluing Section
Knurled stainless steel coating roller assures even glue distribution. Three sensors auto-control glue level. Copper side stoppers prevent overflow at high speed and enable glue re-circulation.
Multi-Sensor Registration
Multiple sensors monitor bottom-sheet feeding position. Two upper servo motors synchronously adjust top-sheet timing for accurate register at any production speed.
Maintenance-Free Transmission
Multi-power gear-and-belt distribution: low noise, high efficiency, no manual lubrication on main shafts. Main gluing-roller gears sourced from a Taiwan supplier for long service life.
Automatic Grease Lubrication
DALOMA centralised lubrication system feeds all critical bearings on a programmed cycle. No manual greasing during shifts — a major reliability gain for two-shift operations.
Press Conveyor for Bonding
Standard press conveyor collects laminated sheets for perfect bonding under controlled pressure. Conveyor speed adjustable to track machine speed, single-motor drive.
PLC Touch-Screen HMI
Man-machine interface with PLC control, warning indicators, automatic monitoring, irregularity detection, job memory and one-key test run. The HMI boots with the SAGLIN logo by default.
Where the SAGLIN-DX-1450 is at work.
Designed for converters who need consistent registration on heavy boards at sustained production speeds. Three application profiles where the machine pays back fastest.
Litho-Laminated Shipping Boxes
High-quality printed top sheet on 3-ply or 5-ply corrugated bottom. Volume box converters serving FMCG, electronics, and online retail benefit from the SAGLIN-DX-1450’s stability on long runs without registration drift.
Heavy-Duty Transit Cartons
For 5-ply and 7-ply boards up to 10 mm thick. The dual-servo bottom feeder handles stiff multi-ply stocks that fail on chain-driven machines, opening segments like white goods, automotive parts, and beverage transit packaging.
Display & Promotional Packaging
Where shelf appearance matters — printed and laminated grey-board displays, in-store POS, gift transit boxes. ±1 mm accuracy means the lamination can run directly into die-cutting without trimming losses.
The SAGLIN-DX-1450 is the heart of our Corrugated Packaging Line.
Combine with the SAGLIN-DX-FZ1450 stacker, our SAGLIN-DX-PT1450 pile turner, and optional film-laminating, varnishing, or window-patching modules — turnkey investment configured to your spec, with typical 12–24 month payback for two-shift converters.
Built with components you trust.
Every SAGLIN-DX-1450 ships with the same global-brand component baseline — no compromise to lower the price point.
Questions buyers ask before signing.
What is the realistic production speed in a Russian factory?
Is the machine EAC certified?
What is the typical lead time and delivery schedule?
What spare parts inventory should I keep?
Can the SAGLIN-DX-1450 run grey paperboard for premium packaging?
What warranty and after-sales coverage do I get?
