SAGLIN-MTM·E SERIES
Multi-Functional
High-Speed Film Laminator
Five proven configurations spanning 1080 mm and 1300 mm working widths — engineered for offset and digital print houses scaling from B2 to B1 production.
Built for the print house scaling into premium finishing.
The SAGLIN-MTM·E series is a fully automatic vertical dry-lamination film laminator designed for converting offset-printed sheets into laminated, ready-to-die-cut substrates. The series covers water-based polyurethane gluing, thermal lamination with pre-glue coated film, and dry lamination of MPET, OPP, BOPP gloss/matte, and PVC films at production speeds up to 80 m/min.
“From 150 LPI ceramic anilox rollers to 28 kW electromagnetic drying — the MTM·E series delivers consistent gloss and bond strength across long, multi-shift production runs.”
The series spans five configurations engineered to match different sheet sizes and budget points: SAGLIN-MTM-108E and SAGLIN-MTM-108E3 for half-format printers, SAGLIN-MTM-145E for half-format with longer sheet length, and SAGLIN-MTM-145D / SAGLIN-MTM-165D for full-format B1 production. All five share the same drive geometry, gluing system, and electromagnetic drying core — only the sheet handling and frame width differ.
Every machine ships with electrical and pneumatic specifications adapted for the Russian and CIS markets (380 V / 50 Hz, EAC certification support), and can be installed and commissioned by our partner HD RUS LLC in Moscow.
Why printers choose the MTM·E
- Servo-controlled high-speed feeder, paper pile height 1250 mm
- 150 LPI ceramic anilox roller — 5 g/m² glue consumption
- Two-stage 28 kW electromagnetic drying — energy-efficient
- Lamination roller pressure up to 12 tons
- UPS provision keeps gluing rollers running on power loss
- Electrostatic paper-powder removal before gluing
- Banana rollers prevent film wrinkles at high speed
- Non-stop feeder and delivery for continuous operation
Five-model comparison.
All five models share the same drive geometry, gluing system, and drying technology. The key choices are sheet size and cutting type.
| Model | SAGLIN-MTM-108E | SAGLIN-MTM-108E3 | SAGLIN-MTM-145E | SAGLIN-MTM-145D Popular | SAGLIN-MTM-165D |
|---|---|---|---|---|---|
| Max Laminating Width | 1080 mm | 1080 mm | 1080 mm | 1300 mm | 1300 mm |
| Max Sheet (W×L) | 1080×1080 | 1080×1080 | 1080×1450 | 1300×1450 | 1300×1650 |
| Min Sheet (W×L) | 350×350 | 400×350 | 400×350 | 400×350 | 400×350 |
| Paper Thickness | 100–500 gsm | 150–500 gsm | 150–500 gsm | 150–500 gsm | 150–500 gsm |
| Film Thickness | 6–25 μm | 10–25 μm | 10–25 μm | 10–25 μm | 10–25 μm |
| Lamination Speed | 10–80 m/min | 10–80 m/min | 10–80 m/min | 10–80 m/min | 10–80 m/min |
| Overlap Precision | ±2 mm | ±2 mm | ±2 mm | ±2 mm | ±2 mm |
| Total Power | 63-68 kW | 71.5 kW | 71.5 kW | 71.5 kW | 71.5 kW |
| Power Supply | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz |
| Machine Weight | 8600 kg | 8500 kg | 9500 kg | 10200 kg | 10200 kg |
| Machine Length (L) | 10765 mm | 10204 mm | 12994 mm | 10330 mm | 10330 mm |
| Machine Width (W) | 2754 mm | 2366 mm | 2366 mm | 2366 mm | 2366 mm |
| Machine Height (H) | 2926 mm | 2900 mm | 2900 mm | 2900 mm | 2900 mm |
| Cutting Type | Chain Knife | + Disc Knife | Chain Knife | Chain Knife (E4 hot knife optional) | Chain Knife (E4 hot knife optional) |
Lamination speed and overlap precision depend on paper quality, film type, and operator experience. The 80 m/min top speed is verified on calibrated 250 gsm coated stock with BOPP gloss film. Specifications are subject to change without notice as part of continuous improvement.
Three knife options. Choose by film type and budget.
The cutting module separates laminated sheets after the press section. The choice between chain, disc, and hot knife depends on the films you run most often and your tolerance for pre/post-trim handling.
Chain Knife
Servo-controlled chain knife with ultrasonic-sensor and encoder positioning. Suitable for OPP, PET, and metalized films across partial and multi-roll lamination. The default cutting module across the entire MTM·E series.
Available on: all five models
Surcharge: none — included in base price
Chain Knife + Disc Knife
The E3 option adds a disc-knife module alongside the standard chain knife. Provides flexibility for substrates that respond better to rotary cutting — particularly heavier laminated stocks and certain PVC films.
Designation: SAGLIN-MTM-108E3 — factory-configured
Surcharge: available on request
Steinemann Hot Knife
Optional Steinemann (Switzerland) hot-knife technology with servo-controlled tracking and tension control. Keyence laser-sensor positioning. Recommended for premium PET, OPP, PVC, and metalized PET at the highest production speeds. Includes paper-flatness anti-curl device.
Available on: SAGLIN-MTM-145D, SAGLIN-MTM-165D (E4 option)
Surcharge: available on request
Eight engineering advantages.
Common to all five MTM·E models — the design language that distinguishes a serious post-press laminator from generic box-coater equipment.
High-Speed Servo Feeder
Servo-controlled feeder with 4 lifting and 4 forwarding suckers. Non-stop pre-stacking system, 1250 mm pile height. Min/max table protection sensors.
Stainless Conveying Table
Customized stainless-steel conveyor with two suction motors to prevent sheet slippage. Servo-controlled feeder belt and front lay (×2). Overlap tolerance ±2 mm.
Electrostatic Powder Remover
1 kW electrostatic paper-powder removal roller before gluing. Roller heating 0–60 °C. Paper-missing sensor included. 150 mm steel + rubber roller pair.
150 LPI Ceramic Anilox Gluing
Precision ceramic anilox roller, 150 LPI, runout accuracy 0.001 mm. Even gluing without stripes. Glue consumption only 5 g/m². Teflon-coated tray and doctor blade for fast cleaning.
28 kW Electromagnetic Drying
800 mm dry roller with 25 L heat-transfer oil, twin 28 kW electromagnetic heaters. Hot-air blow system for fast glue drying. 36-element 28.8 kW oven heaters up to 150 °C.
12-Ton Lamination Pressure
350 mm laminating pressure roller with 18 L heat-transfer oil. 280 mm rubber pressure roller. Maximum lamination pressure 12 tons. Banana rollers prevent film wrinkles.
Magnetic Powder Brake Tension
Lightweight 3″ air shaft with film-loading stacker. Magnetic powder brake tension control prevents film curling. Optional slip shaft and dual-roll air shaft for multi-roll lamination.
Siemens HMI · Remote Diagnosis
Siemens PLC and HMI with real-time production data, error display, and solution prompts. Speed, sheet count, temperature on one screen. UPS keeps gluing rollers running on power loss.
Where the MTM·E pays back fastest.
Three end-markets where the MTM·E series sits in production today across the global SAGLIN installed base.
Folding Cartons with Soft-Touch Finish
Soft-touch BOPP matte and gloss BOPP on offset-printed skincare and perfume cartons. The combination of 5 g/m² glue consumption and 12-ton lamination pressure delivers the wrinkle-free finish premium cosmetics buyers demand.
Book Covers & Hardback Wraps
Thermal lamination with pre-glue coated film for school textbooks, soft-touch matte for premium hardcover wraps. The non-stop feeder system handles long single-title runs without operator intervention.
Brochures, Folders & Menus
Water-based gloss BOPP for corporate brochures, presentation folders, and laminated restaurant menus. The dominant MTM·E application in the Russian and CIS markets — short-to-medium runs with mixed film types.
The MTM·E is the heart of our Premium Print-Finishing Line.
Combine with offset-press loading systems, pile turners, and downstream die-cutting modules. Configured to your throughput target with typical 12–24 month payback for two-shift print houses.
Built with components you trust.
Every MTM·E ships with the same global-brand component baseline — selected for stability over the 10-year service life expected of post-press equipment.
Questions buyers ask before signing.
What’s the difference between SAGLIN-MTM-108E, SAGLIN-MTM-108E3, and SAGLIN-MTM-145E?
SAGLIN-MTM-145D vs SAGLIN-MTM-165D — how do I choose?
Chain knife vs hot knife — what’s the production difference?
Is the machine EAC certified?
What is the typical lead time and delivery schedule?
What films and adhesives are compatible?
Can the machine produce de-plastic (recyclable) laminate?
What warranty and after-sales coverage do I get?
Request a quote for your MTM·E line.
Tell us your sheet size, target film mix, and monthly volume. We respond within 24 hours with a model recommendation, detailed quotation, line layout proposal, and ROI estimate.
